Electric Portable Automatic Strapping Machine for 13/16mm PP Pet Strap
PRODUCT DESCRIPTION
Semi-automatic Electric Strapping machine widely used in food, medicine, hardware, chemical, clothing, postal and other industries. They are suitable for carton packaging, pallet packaging, paper packaging, parcel letter packaging, medicine box packaging, light industry packaging, hardware tool packaging, ceramic product packaging, auto parts packaging, automatic packaging and packaging of various sizes of goods.
| Strap material |
PP, PET strap |
| Strap width |
12-16mm(adjustable) |
| Strap thickness |
PP(0.4-1.0mm)
PET(0.5-1.0mm)
|
| Applicable Straps |
Polypropylene (PP) and Polyester (Pet) |
| battery life |
Up to approx 2000 times |
| Working quantity after charging once |
100-200 times |
| Power |
Lithium Battery (DC14.4V, 3000mAh,10c) |
| Strap Sealing Form |
Friction Weld Sealing |
| Tension Range |
60-2100(N) or 6-214(Kg)Adjustable |
| Sealing time |
1-3 seconds |
| Weight |
3.9kg |
ADVANTAGE
Handle plastic electric trapping machine advantage:
a) Reduce packing cost more than 15% and improve the combining intensity about 2 times
b) Improve packing without the metal buckle
c) With the alarm devise for the low power and finishing;
d) Works normally under a large number of dust, tiny fiber and other abominable environments with the exceptive dust-proof filter screen;
e) With the light weight,easy to operate in single- hand.
FEATURE
Economical and applicable, simple operation
1.Wrapping belt
2.Insert packing tape
Lift the handle with your right hand,insert it into the packing belt with your left hand,stack the upper and lower parallel,and release the handle.
3.Tighten the strap
Press the tension switch,and release the switch button after the tension strength of the packing belt is reached.4.Bonding of contacts
Press the welding button,the hand will leave immediately,the plastic steel belt will be welded and the excess packing belt will be cut off,welding is completed.
5.Remove the packing tool
Lift the handle to loosen the belt and pull the packer to the right away from belt.
WHY CHOOSE JIATUO MACHINERY
1. Professional Extruder Manufacturer: Jiatuo Machinery has more than 20 experienced engineers to serve the machinery production workshop, and we have our own straps production workshop. We can find machine defects in the strap production process and make improvements in time.
2. Best Price: Jiatuo Machinery is located in China's famous wholesale city, with sufficient accessories and favorable price, which could save machine manufacturing costs.
3. High Quality: The electronic components adopt international brand, the machine uses 20% thickened steel, which makes the machine run more stable. And the water tank adopts corrosion-resistant stainless steel 304 model.
4. High Output: the machine adopts hot air drying system, automatic feeding system and flow pump control system, so that the machine can produce stable output in production
5. Low Energy Consumption: Using electromagnetic heating system, the power consumption is reduced by 20%.
6. Free Installation Training: More than 20 technicians solve all the problems encountered in the production process online 7x24 hours, and return to normal production as soon as possible.
