PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed

PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed
PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed

Large Image :  PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JT-Packing Straps
Payment & Shipping Terms:
Minimum Order Quantity: 1 Ton
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 5~7working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50000 Roll/Rolls per Week

PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed

Description
Product Name: PET Packing Straps Band Type: PET Steel Strap
Material: PP PET As Customized Requirements Brand Name: Custom Logo And Printing
Strap Locking Method: Clip Method, Hot Melt Method Strap Feature: Embossed, Weather Resistant, Safe And Econimical, Split Resistant.
Strap Surface: Woven, Embossed, Smooth Straps Strap Grade: Packing Straps For Hand Grade / Semi Or Full Auto Machine Grade
Packing: Roll/ Carton/ Pallet Usage: Straps Used For Combining, Stabilizing, Holding...
Highlight:

PET Strapping Production Line

,

PET Steel Strap Embossed Belt Roll

,

Colored Pet Packing Strap Belt Roll

PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed or Smooth

PRODUCT DESCRIPTION



PET strapping production line equipment features:

The production line uses PET waste mineral water, Sprite, cola and other bottle pieces as raw materials to produce packing belts with low cost and high efficiency. The latest computer control system is used for real-time control of melt temperature, pressure, extrusion speed, torque, traction, etc. to ensure product quality.

Specification Width Thickness Pull force Total weight Net weight Core Diameter Length
PET-0905 9.0mm 0.50mm >150kg 20kg 18.5kg 200/406mm 3400m
PET-1205 12.0mm 0.50mm >210kg 20kg 18.5kg 200/406mm 2500m
PET-1206 12.0mm 0.60mm >240kg 20kg 18.5kg 200/406mm 2300m
PET-1606 16.0mm 0.60mm >350kg 20kg 18.5kg 200/406mm 1480m
PET-1608 16.0mm 0.80mm >500kg 20kg 18.5kg 200/406mm 1080m
PET-1610 16.0mm 1.00mm >520kg 20kg 18.5kg 200/406mm 970m
PET-1908 19.0mm 0.80mm >550kg 20kg 18.5kg 200/406mm 1020m
PET-1910 19.0mm 1.00mm >700kg 20kg 18.5kg 200/406mm 740m
PET-1912 19.0mm 1.20mm >850kg 20kg 18.5kg 200/406mm 660m
PET-2510 25.0mm 1.0mm >1000kg 20kg 18.5kg 200/406mm 500m
PET-2512 25.0mm 1.2mm >1100kg 20kg 18.5kg 200/406mm 500m

Specifications can be customized according to customer requirements.

PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed 0

Plastic PET Polyester strap

Packaging with PET plastic band is very reliable, polyester straps (PET) are better and but expensive than polypropylene band (PP). Basically, it is considered that PET straps with the same dimensions 2x are stronger than PP strap. When considering which plastic strap you should choose, it depends on the weight of the load, how stable it should be, what is your price range and in what conditions the goods will be transported and lastly what are you transporting.

Plastic PET Polyester band

We offer only high-quality polyester straps they are characterized by high breaking strength in combination with a good recovering capacity and a high resistance against an impact load. Plastic PET bands can be used for strapping pallets or other packages. For productive packing, we suggest using them in combination with battery strapping tools or other packing machines. Especially with heavy-duty applications and long-term storage and/or transport this strap guarantees the highest possible stability of the load.



PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed 1


The use of PET packing belt:

1. Straps: The packing belt will be tied with the package.Your left hand will hold the overlap part and reserve the tail about 300mm.Then you can gently pull out the rest with your right hand.Packing: Holding the handle and tensioner with your right hand(In order to ensure the distance between the tension wheel and platen hanging tooth is the largest).To insert the upper and lower parts of straps into the strapping machine.Another special reminder: the overlap of the straps must be separated by the lower blade of the stationary cutter;Loosen the tensioner (tight wheel clamped packing tape tightly).



2. Tighten the packing tape: To hold the tension switch lever (right) with right hand (right) and don't relinquish until the packing tape is completely tight.



3. Vibration and cut off: To press and hold the vibrating switch lever with your right hand and don't move away until the strapping tape is cut off. A Special reminder: To press and hold vibration switch lever of the pneumatic baler until the vibration timer stops automatically.



4. Remove the strap:To squeeze handle and tensioner and use your right thumb to hold the transfer switch until the straps are loosened from the pinch rollers.Then, tightening the handle and tensioner to remove the tool from the strap.

PET Strapping Production Line Colored Pet Packing Strap Roll With Embossed 2
