Single Screw 2 Belts PP Strap Making Machine Carton PP strapping tape production line Box Packing Strap Machine

Single Screw 2 Belts PP Strap Making Machine Carton  PP strapping tape production line Box Packing Strap Machine
Single Screw 2 Belts PP Strap Making Machine Carton  PP strapping tape production line Box Packing Strap Machine Single Screw 2 Belts PP Strap Making Machine Carton  PP strapping tape production line Box Packing Strap Machine Single Screw 2 Belts PP Strap Making Machine Carton  PP strapping tape production line Box Packing Strap Machine Single Screw 2 Belts PP Strap Making Machine Carton  PP strapping tape production line Box Packing Strap Machine

Large Image :  Single Screw 2 Belts PP Strap Making Machine Carton PP strapping tape production line Box Packing Strap Machine

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPP-100
Document: parameter details of PP Str...ne.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50set/month

Single Screw 2 Belts PP Strap Making Machine Carton PP strapping tape production line Box Packing Strap Machine

Description
Product Type: PP Packing Belt Extrusion Line Raw Material: Polypropylene PP Raw Material Pellets, Recycled Pellets
Screw Design: Optional Twin Screw Type: Co-rotating Parallel Twin-screw
Driven Type: Electric Processing Type: Extruding Machine
Automation: Automatic Application: Packaging Strap
Warranty: 1 Year Width: 5-19mm
Highlight:

PP Strap Extrusion Line Single Screw

,

PP Packing Strap Belt Extrusion Line

,

Carton Box PP strap Extrusion Line

Single Screw 2 Belts PP Strap Making Machine Carton  PP strapping tape production line Box Packing Strap Machine

PRODUCT DESCRIPTION


1.Single screw or twin screw technique for option depending on the requirement.
2.100% recycled flakes can be used for production.
3. Even plasticization and stable extrusion with PC automatic control for the full line.
4. The fiflter of double columns with four working positions can get rid of impurity effective.
5. Single strap or double strap for option.


NO.NameQTY
1Color Mixer1 set
2Vacuum feeder or screw loader feeder
(100% raw material use vacuum feeder machine;recycled material use screw loader feeder machine) customer choose one of it.
1 set
3Hopper dryer1 set
4SJ single screw extruder1 set
5High speed Screen exchanger device1 set
6Molud1 set
7Water cooling tank1 set
8The first traction machine- 5 rollers1 set
9The first Stretch forming oven1 set
10The Second traction machine- 5 rollers1 set
11The second Stretch forming oven1 set
12The Third traction machine- 3 rollers1 set
13Embossing machine1 set
14The Winder machine1 set



Single Screw 2 Belts PP Strap Making Machine Carton  PP strapping tape production line Box Packing Strap Machine 0

APPLICATION & FEATURES



  • The features of line are as follows: screw with compression ratio especially for PP/PET, gradually changing diameter and deeper thread groove at the melting part; gearbox with hardened gears; die can be precisely adjusted to ensure stable production and smooth surface of straps; stainless steel cooling trough with four thermo treatment processes displaces the traditional one; haul off rollers with bigger size ensure the quality of products; new rolling technology overcomes the shortcomings of traditional rolling machine like high gradient and bending delection; laser embossing roller makes clear and even patterns.
  • PET packing strap is widely used, replaced for steel strap for packing application internationally, because of its good tensile strength, flexible, low prolongation rate, good performance of high temperature resistant, non-rustiness, and low use-cost, etc, it is used in steel, construction material, chemical fiber, paper making, tobacco, agriculture, election, etc.


Single Screw 2 Belts PP Strap Making Machine Carton  PP strapping tape production line Box Packing Strap Machine 1
About After-sales
We provide comprehensive technical support and service for our PP Strap Making Machine. Our team of experienced technicians can provide a variety of services, including:
Pre-sales:
1.Layout plan of PP belt making machine.
2.Analysis of the cost of PP tape making machine.
3.Raw materials that can be used for PP tape making machine.
After-sales service:
1.Water and electricity circuits of PP belt making machine, circuit drawings, etc.
2.Installation, commissioning and training of PP belt making machine.
3.Maintenance service of PP belt making machine.
4.Regular maintenance and repair
5.Troubleshooting and diagnosis
6.Software updates and upgrades
7.Spare parts and accessories
8.Training and technical advice
Single Screw 2 Belts PP Strap Making Machine Carton  PP strapping tape production line Box Packing Strap Machine 2

FAQ

Q1:Are you a trading company or a factory?

A1:We are a factory,can give u best service.


Q2:When can I get my machine after I paid?

A2:We will deliver the machines on time as the date we agreed both side.


Q3:How can I install my machine when it arrives?
A3:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.



Q4:What's your guarantee or the warranty of the quality if we buy your machines?

A4:We offer you high quality machines with 1 years guarantee . we will give u spare part free in 1 years.
Single Screw 2 Belts PP Strap Making Machine Carton  PP strapping tape production line Box Packing Strap Machine 3
