Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment

Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment
Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment

Large Image :  Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JT-PP
Document: parameter details of PP Str...ne.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram

Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment

Description
Product Type: PP Strap Making Machine Raw Material: PP
Processing Type: Extruding Machine Screw Design: Single-screw,Double-screw,single Or Double
Application: Sheet,Strap,Pipe,packaging Band,Tape And Strap Driven Type: Electric
Automation: Automatic Voltage: 220V-240V
Warranty: 1 Year After-sales Service Provided: Engineers Available To Service Machinery Overseas
Highlight:

19mm PP Strap Band Extrusion Line

,

250m/min plastic strap making machine

,

PP Strap Band Extrusion Line 250m/Min

Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment

PRODUCT DESCRIPTION



PP strapping tape production equipment is a high-speed extruder that can produce PP strapping tape for strapping various products.

It has the following features:

1. High-speed extrusion------- It uses a high-efficiency extruder, quantitative extrusion, high production capacity, to ensure fast and continuous production, 24-hour power outages, and can produce 2-12 PP tapes at the same time.

2. Automatic control------- PLC automatic system control, easy debugging, reduce manual intervention, and improve production efficiency.



Machine size (L*W*H) mm 3600*1200*4000
Product arrange mode PP One out four
Extrusion Capacit(kg/h) 240
Speed (m/min) more than 250
Number of Straps 4
PLC control system PLC
Outgoing band width(mm) 5-19
Band Thickness(mm) 0.4-1.2
Capacity per day 5.7 T





About the transmission mode of the five-roller gearbox:
1. Synchronous belt drive
2. Gearbox drive

Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment 0


APPLICATION & FEATURES



  • PP raw materials do not need to separate the dry and water treatment . There are automatic circulation on preheating and

drying that save a large number of equipment investment and reduce the production cost by 30%;

  • Utilizing the retrieving bottle slice as raw materials that reducing the cost to a great extent;



  • With the multi-purpose machine, produce the PP PET straps in different specifications directly and don not need to change the mould head;


Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment 1

Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment 2


FAQ



1. For PP(polypropylene) strapping band extrusion line
* What about the output of PP strapping band extrusion line? 150kg/hr, 280kg/hr, 500kg/hr.
* What about the usage of PP strap? Packing boxes, money, paper.
* Will the strap be used for automatic strapping tool or manual tool? Both.

2. For PET(polyester) strapping band extrusion line
* What about the output of PET strapping band extrusion line? 200kg/hr, 400kg/hr, 600kg/hr, 800kg/hr.
* What about the usage of PET strap? Packing cotton, aluminum, wood, brick, boxes.
* Will the strap be used for automatic strapping tool or manual tool? Both.



WHY CHOOSE US


1. We major in Pet Strap Production Line for 20 years
2. Can use 100% recycled bottle flakes material
3. The final straps can be packed automatically
4. Always have at least 3 sets of sample machine in our workshop
5. Can take customers to see the running machines
6. Can test the machine for customers

Packaging machinery 5-19mm PP strapping production line PP strapping production equipment with high speed extrusion equipment 3
