Brick Kiln PET Strap Making Machine 12mm Extrusion Line 300kg/H With Strong Strength

Brick Kiln PET Strap Making Machine 12mm Extrusion Line 300kg/H With Strong Strength

Product description

The machine is mainly used to make plastic strap ,PET PP packing strap . Adopt the plc control the whole line do the auotmatic production it use the melting pump and pressure sensor ensure the production stable and strap quality control .
The raw material you can use is 100% recycled PET flakes from the waste pet bottles,or virgin material or mixed with each PP strap production line is used to produce mechanical or manual bands with 100% PP recycled granules as materials, if raw materials, it will be better.

PET Strap Production Line Machine List

Features of PET packing strap production line:

1. The extruder adopts PET special screw with unique parameter design. The screw has a unique separation and mixing effect, which ensures the uniform plasticization of raw materials. It has large extrusion volume, good plasticization, high hardness and high wear resistance. Etc.

2. The three-dimensional folded super-large area filter device, the unfolded area of ​​the filter screen is 30 times larger than that of the traditional flat filter screen; the filtering mesh number can reach 80 meshes, and the unique screen changing device greatly reduces the screen changing time and improves the work efficiency.

3. Using the rotary honeycomb dehumidification and drying system to dry the raw materials, the dew point of -50 °C ensures that the moisture content of the raw materials is ≤50PPM, and it has the effect of solid-phase polycondensation and viscosity enhancement.

4. The equipment adopts a unique two-stretching process, which has good rigidity and stable width, and improves the tensile strength of the finished product.

5. High-precision parts make the product molding quality stable, and the width and thickness fluctuations are far smaller than the national standard;

6. The unique oven circulation heating system adopts reciprocating winding method inside, making full use of thermal energy to greatly reduce power loss.

7. The unique circulating cooling system and multiple sets of shaping belt guide rollers make the packaging belt cooling and shrinking and shaping more fully, the product is more stable and the size is more accurate.

8. Five-roller traction system, stable traction, smooth equipment operation, reduced failure rate, and reduced maintenance costs by 60%.

9. High-precision special embossing and pressing device, adjustable pressure, the embossing wheel can be synchronized up and down, the embossing is clear and beautiful, and the product quality is comparable to that of European, American, Japanese and Korean packing belts.

10. Constant force winding system, unique design parameters, in line with high output, excellent winding effect, flat and beautiful on both sides.

11. The rewinder adopts a double-station rewinding device, which is easy to operate and easy to change.

12. It can all be produced with 100% bottle flakes, and the quality of the finished product can be compared with brand new materials.

DETAILS ABOUT PET STRAP MAKING MACHINE

1. Components of pp pet packing belt machinery:
PET Strap Production Line consists of dehumidifying and crystallizing system, extruder, screen changer, mold, oven, haul-off, and winder, etc.

2. Production Process of PET Machinery
Material→ Dehumidifying and Crystallizing → Extruding → Mold → Cooling → Haul-off →Oven Heating →Pre-heating → Drawing and Stretching →Drawing and Stretching → Embossing →Hot Forming → Drawing → Winding

3. Application
With 100% bottle flakes recycled material, to produce various specifications of PET strap. It has been widely used in steel, chemical industry, aluminum, paper making, brick kiln, tobacco, electronics and textile and timber industries.
