Polyester Strapping Plastic Packing Belt Steel Green PET Hand Belt

Polyester Strapping Plastic Packing Belt Steel Green PET Hand Belt
Polyester Strapping Plastic Packing Belt Steel Green PET Hand Belt Polyester Strapping Plastic Packing Belt Steel Green PET Hand Belt Polyester Strapping Plastic Packing Belt Steel Green PET Hand Belt

Large Image :  Polyester Strapping Plastic Packing Belt Steel Green PET Hand Belt

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JT-Packing Straps
Payment & Shipping Terms:
Minimum Order Quantity: 1 Ton
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 5~7working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50000 Roll/Rolls per Week

Polyester Strapping Plastic Packing Belt Steel Green PET Hand Belt

Description
Product Name: PP & PET Packing Straps Band Material: PP Or PET As Customized Requirements
Brand Name: Custom Logo And Printing Strap Locking Method: Clip Method, Hot Melt Method
Strap Feature: Embossed, Weather Resistant, Safe And Econimical, Split Resistant. Strap Tensile Strength: 50Kgs ~ 460Kgs, As Customized Details Requirement
Strap Surface: Woven, Embossed, Smooth Straps Strap Grade: Packing Straps For Hand Grade / Semi Or Full Auto Machine Grade
Packing: Roll/ Carton/ Pallet Usage: Straps Used For Combining, Stabilizing, Holding...
Highlight:

Plastic Steel Strapping Packaging Belt

,

Polyester PET Steel Packaging Belt

,

Polyester Strapping Packing Belt

Polyester Strapping Packing Plastic Steel Packaging Belt Green PET Hand Belt

PRODUCT DESCRIPTION



PET strapping packing belt, also known as packing tape, strapping tape or PET strip.The main component of PET is polyester resin.Its appearance: transparent. Its flammability: flammable, continue to burn after leaving the flame. Its flame is yellow with black smoke;it slightly swollen, sometimes dehiscent with styrene odor. Its chemical composition is based on polyethylene terephthalate as the main raw material by finishing.The processing of pet plastic packagin is that put the material into into the screw in injection molding machine, after heating, extrude through the grinding head.The material be put into the sink for cooling and through the second traction,the PET strip finish a pultrusion. Then, the material be put into the embossing wheel and press out the pattern, and be entered into the cooling sink again through fetch water or wind power to blow-dry. At last,the third traction pull out the fashioned PET strip and transfer into the winding machine for winding and finish its packaging. Plastic strip is currently a new type of ring packaging materials which used to replace the steel strip in the world, and widely used in metallurgical building materials and other industries. PET packing belt has low cost and easy to use.The advantages of environmental safety are favored by more and more customers.But, many people often encounter some problems in use. Now, i will tell you some simple operation method of packaging.
Specification Width Thickness Pull force Total weight Net weight Core Diameter Length
PET-0905 9.0mm 0.50mm >150kg 20kg 18.5kg 200/406mm 3400m
PET-1205 12.0mm 0.50mm >210kg 20kg 18.5kg 200/406mm 2500m
PET-1206 12.0mm 0.60mm >240kg 20kg 18.5kg 200/406mm 2300m
PET-1606 16.0mm 0.60mm >350kg 20kg 18.5kg 200/406mm 1480m
PET-1608 16.0mm 0.80mm >500kg 20kg 18.5kg 200/406mm 1080m
PET-1610 16.0mm 1.00mm >520kg 20kg 18.5kg 200/406mm 970m
PET-1908 19.0mm 0.80mm >550kg 20kg 18.5kg 200/406mm 1020m
PET-1910 19.0mm 1.00mm >700kg 20kg 18.5kg 200/406mm 740m
PET-1912 19.0mm 1.20mm >850kg 20kg 18.5kg 200/406mm 660m
PET-2510 25.0mm 1.0mm >1000kg 20kg 18.5kg 200/406mm 500m
PET-2512 25.0mm 1.2mm >1100kg 20kg 18.5kg 200/406mm 500m

Specifications can be customized according to customer requirements.

Polyester Strapping Plastic Packing Belt Steel Green PET Hand Belt 0

The use of PET packing belt:

1. Straps: The packing belt will be tied with the package.Your left hand will hold the overlap part and reserve the tail about 300mm.Then you can gently pull out the rest with your right hand.Packing: Holding the handle and tensioner with your right hand(In order to ensure the distance between the tension wheel and platen hanging tooth is the largest).To insert the upper and lower parts of straps into the strapping machine.Another special reminder: the overlap of the straps must be separated by the lower blade of the stationary cutter;Loosen the tensioner (tight wheel clamped packing tape tightly).



2. Tighten the packing tape: To hold the tension switch lever (right) with right hand (right) and don't relinquish until the packing tape is completely tight.



3. Vibration and cut off: To press and hold the vibrating switch lever with your right hand and don't move away until the strapping tape is cut off. A Special reminder: To press and hold vibration switch lever of the pneumatic baler until the vibration timer stops automatically.



4. Remove the strap:To squeeze handle and tensioner and use your right thumb to hold the transfer switch until the straps are loosened from the pinch rollers.Then, tightening the handle and tensioner to remove the tool from the strap.


Polyester Strapping Plastic Packing Belt Steel Green PET Hand Belt 1
PET packing belt Features & Advantages
1. Strong tensile strength/ strong pulling power;
2. Good adhesive ability;
3. Low elongation/small bending degree;
4. Strong heat resistance;
5, beautiful and not rusty;
6. High economic benefits;
These characteristics make it more suitable for large or heavy material packaging, and more suitable for long-distance transportation.

Polyester Strapping Plastic Packing Belt Steel Green PET Hand Belt 2
